Product Name:Passive NFC 3M Adhesive Epoxy Sticker
Description
With epoxy the NFC Adhesive stticker can be protected and not easy to tear up,the useing time can be extend,the epoxy side also very soft,easy to be used.Also can make the RFID Sticker waterproof.It's your best choose if need your RFID tag used for longer time and waterproof.Please contact us now.
Specification
1.Material:Coated Paper/PVC/PET
2.Frequency:LF 125-134.2Khz,HF 13.56Mhz,UHF 860-960Mhz
3.Dimension:25-26-28-30-35mm round or square shape, or custom shape
4.Printing:CMYK full color printing, silk printing or digital printing
5.Sample:nfc token tag free sample available
6.Crafts:
Logo: Digit printing, offset printing and silk printing
Number printed will be available ( Serial No & Chip UID)
Collect UID code excel,text file etc.
Chip program/encode will be available as well ( URL ,TEXT ,Number and Vcard)
Epoxy, Customize size and shape , Hole punch etc
Available Chips:
Protocol ISO/IEC 14443A:
1: MIFARE Classic reg; 1K, MIFARE Classic reg; EV1 1K, MIFARE Classic reg; 4K
MIFARE and MIFARE Classic are registered trademarks of NXP B.V. and are used under license.
2: MIFARE Plus reg; S 1K, MIFARE Plus reg; S 1K SE, MIFARE Plus reg; S 2K / S 4K, MIFARE Plus reg; X 2K / X 4K， MIFARE Plus reg; EV1 2K / 4K
MIFARE and MIFARE Plus are registered trademarks of NXP B.V. and are used under license.
3: MIFARE reg; DESFire reg;
MIFARE reg; DESFire reg; 2K / EV1 2K / EV2 2K
MIFARE reg; DESFire reg; 4K / EV1 4K / EV2 4K
MIFARE reg; DESFire reg; 8K / EV1 8K / EV2 8K
MIFARE DESFire are registered trademarks of NXP B.V. and are used under license.
4: NFC Forum Type 2:
1) NTAG reg; 203 (144 bytes), NTAG 213 (144 bytes), NTAG reg; 215 (504 bytes), NTAG reg; 216(888 bytes), NTAG reg; 210 (48 bytes), NTAG reg; 212 (128 bytes)
NTAG reg; are registered trademarks of NXP B.V. and are used under license.
2) MIFARE Ultralight reg; (48 bytes) MIFARE Ultralight reg; EV1 (48 bytes/128 bytes) MIFARE Ultralight reg; C(148 bytes)
MIFARE and MIFARE Ultralight are registered trademarks of NXP B.V. and are used under license.
Protocol ISO 15693/ISO 18000-3:
ICODE reg; SLIX, ICODE reg; SLIX-S, ICODE reg; SLIX-L, ICODE reg; SLIX 2
ICODE reg; are registered trademarks of NXP B.V. and are used under license.
