The tag is flexible and can be stuck on metallic assets easily, specially for irregular and uneven surface, such as steel boiler, metal container, steel pipe, etc. It has good performance on metal and can be printed with logo, numbers, text by RFID printers, such as Zebra ZT410 Silverline,Sato CL4NX,Toshiba SX-5,Postek TX3r,etc.Synchronous encoding is also available.
Item NO. :
UHF RFID anti-metal labelPayment
T/T, Western Union, PaypalProduct Origin
Shenzhen, ChinaColor
CustomizedShipping Port
Shenzhen, HongkongLead Time
7-8 working daysBrand
MHProduct Minorder
500
Application
Warehouse shelf
IT asset tracking
Metallic container tracking
Equipment &device tracking
Automotive components tracking
Description:
|
RFID Parameter
|
|
|
Model No.
|
MH-RK7006 |
|
Type
|
Flexible UHF Anti-metal Tag
|
|
Protocol
|
ISO/IEC 18000-6C, EPC Class1 Gen2
|
|
Frequency
|
EU Standard 860-868Mhz, US standard 902-908Mhz, Global frequency
|
|
Chip
|
Impinj Monza MR6-P
|
|
Memory
|
EPC: 128(96)bits
|
|
TID 48bits
|
|
|
Unique TID: 48bits
|
|
|
User: 32(64)bits
|
|
|
Read &Write
|
Supported
|
|
Read Range
|
8 meters
|
|
Data retention
|
10 years
|
|
Programming Cycles
|
100,000 cycles
|
|
Anti-collision
|
Yes
|
|
Physical Parameter
|
|
|
Size
|
95×22×1.26mm / 3.74×0.87×0.049inch
|
|
Substrate Material
|
Transparent Release Film
|
|
Antenna
|
Al(9μm) + PET(50μm) Etched Alumium (9μm) + PET (50μm)
|
|
Surface Material
|
PET Waterproof (Thermal or Transfer Optional)
|
|
Interlayer Material
|
Ferrite Anti-metal
|
|
Encode
|
Supported
|
|
ESD Voltage Immunity
|
Max. 2000V (HBM)
|
|
Printable
|
Supported for RFID printer
|
|
Installation
|
Self adhesive
|
|
Operating temperature
|
-20～+75℃ |
|
Operating humidity
|
20% ~ 90%RH, Non-condensing
|
|
Package
|
500pcs/roll
|
|
Other size option
|
65x35x1.25mm, 55x15x1.25mm, 30x15x1.25mm, 60x25x1mm, 70x30x1mm, 80x40x1mm, 100x40x1mm, 64x6x1mm, 70x50x1mm, etc. |
